Home Construction Hardware Glass Spigots Square Base Round Post Glass Spigot
Spigots For Glass Panels
Spigots For Glass Panels Structure
Spigots For Glass Panels Spigots For Glass Panels Structure

Square Base Round Post Glass Spigot

Part No. LS-NSF

Glass Thickness 12mm
Weight 1.41Kg
Outline Dimension 190mm*104mm*104mm
Material 2205/304/316
Application: Outdoor glass railing, Fence, Balcony railing, Pool fence, Stair handrail, Garden fence, etc.

Glass Spigot Description

This Square Base Round Post Spigots for Glass Panels is used for glass below 12mm, suitable for outdoor glass railings, fences, balcony guardrails, swimming pool guardrails, staircase handrails, garden guardrails. These glass spigots feature a square base for stability and a round post that supports the glass panel. The square base provides a secure foundation when installed on the ground or another surface, while the round post offers a sleek and modern aesthetic that complements the frameless glass panels.

Spigots for glass panels are designed to securely hold the glass panels in place while providing a sleek and minimalistic aesthetic. They offer several advantages, including easy installation, versatility in design, and the ability to create an open and transparent look.

Glass Spigot Specifications

Product Name

Square Base Round Post Glass Clamp

Outline Dimension

190mm*104mm*104mm

Glass Thickness

12mm

Weight

1.41Kg

Finish

Classic Satin/Mirror
Powder Coat Matte Black/White
PVD-Black/Gold/Rose Gold/Gun Grey
Anti-conductive Black/White
Transparent Satin/Mirror

Material

Duplex Stainless Steel 2205, Stainless Steel 304/316

Application

Outdoor Glass Railing, Fence, Balcony Railing, Pool Fence, Stair Handrail, Garden Fence, etc.

Casting Process

Siica Sol Technics Lost-wax Process

Certifications

Australian Standard Test/Patent

Certificate/IATF16949/ISO9001/ISO14001/TUV/PED/AD2000

OEM

Available

Annual Output

2000MT

Tooling Leadtime

2--4 Week

Delivery Time

4--5 Week

Package Specification

Plastic Bag, Bubble Bag.
Paper Carton, Wooden Case, or as Required.



Note

The square base round post spigots for glass panels is suitable for concrete floors and poured concrete floors. Spigots for glass panels come in a variety of finishes, such as brushed stainless steel, polished stainless steel, and black. Choose a finish that complements the overall décor of the space. The spigots must be compatible with the type of glass panel being used.

The square base of these spigots is designed to be securely mounted to the ground or a solid surface using bolts or anchors. The round post extends vertically to hold the glass panel in place, providing structural support while maintaining a clean and unobstructed view.

Spigots For Glass Panels Application
